DC-300A
Automatic Dual-Column Horizontal Band Saw
Part of the International Series, the DC-300A brings full automation to the dual-column format, and it comes fully equipped as standard. A concrete-polymer-filled dual-column frame and four-point hydraulic blade tensioning deliver straight, square production cuts, while a 7-inch PLC touchscreen runs clamping, feeding, and shuttle indexing on its own. You get premium production capability, fully equipped. The DC-300A is also offered as the semi-automatic DC-300, and as the servo-driven DC-300A+, which adds servo ball-screw head feed and material indexing with a 10-inch HMI for higher output and repeatability.
Why the DC-300A
Program the whole cut list in one setup
The DC-300A brings full automation to the dual-column format. For the shop that needs to run full cut lists and finish more parts per shift, with less strain on the operator.
| Specification | Value |
|---|---|
| Cutting Capacity, 90° (Rectangular) | 12.5″ H x 12.5″ W (320 mm x 320 mm) |
| Cutting Capacity, 90° (Round) | 12.5″ (320 mm) |
| Blade Size | 1 1/4″ x 14′ 5″ (34 mm x 4400 mm) |
| Blade Speed (VFD) | 65-265 SFM / 20-80 m/min |
| Blade Drive | 5 HP VFD (3.7 kW) |
| Blade Drive Type | Direct blade drive with German Nord gearbox and motor |
| Indexing | Automatic Multi-Index, up to 23.62″ per stroke (600 mm) |
| Control | 7″ PLC Touch Screen, programmable cut lengths and batch quantities |
| Blade Tensioning | Four-point hydraulic |
| Vise Type | Hydraulic split front vise + floating shuttle vise |
| Hydraulic Tank Capacity | 21.13 US Gal. (80 L) |
| Coolant Tank Capacity | 15 US Gal. |
| Hydraulic Motor | 1 HP (0.74 kW) |
| Electrical Protection | IP54 |
| Table Height | 29.5″ (750 mm) |
| Machine Voltage | 480V, 3-phase, 60Hz standard; 208/240/575V with optional transformer |
| Machine Weight | 3,748 lbs (1,700 kg) |
| Certification | CSA Certified |
WHATS INCLUDED
Standard & Optional Features
Standard Features
Optional Features & Add-ons
Material Handling Options
The DC-300A pairs with roller discharge tables (5 ft and 10 ft), vertical alignment rollers, idler and powered conveyors, and coolant drip pans, filler plates, and forklift cut-outs. Configure a complete production line around the saw.
Ask about material handling →Contact your dealer for current pricing, financing, and availability.
WHY THE INTERNATIONAL SERIES
Built for High-Volume Production Cutting
Real shops choose the DC-300A for full automation, a fully equipped standard spec, and dependable, repeatable production cutting.
COMMON QUESTIONS
What Buyers Ask About the DC-300A
Yes. The 7-inch PLC touchscreen runs clamping, blade feed, head movement, and shuttle indexing automatically. Program cut lengths and batch quantities and the saw repeats them across the run.
Up to 12.5 inches (320 mm) round, and 12.5 x 12.5 inches rectangular, at a straight 90-degree cut. Ideal for solids, structural profiles, and thin-wall tube.
Up to 23.62 inches (600 mm) in a single stroke, with automatic multi-indexing for longer lengths and repeatable length accuracy.
Yes. The DC-300 offers the same rigid dual-column frame in a semi-automatic configuration. For higher output and repeatability, the DC-300A+ adds servo ball-screw head feed and material indexing with a 10-inch HMI.
German Nord direct drive, CSA certification, hydraulic overhead bundling, laser cut-line indicator, mist lubrication, powered wire brush, electrically driven chip auger, out-of-stock detection, and an LED signal tower are all standard. Automatic centralized lubrication, remote pedestal control, and powered transformers are optional.
A 5 HP VFD direct blade drive, driven by a German Nord gearbox and motor, delivers 65 to 265 SFM. Standard supply is 480V, 3-phase, 60Hz (208, 240, or 575V with optional transformers), with IP54 electrical protection, and the machine is CSA certified.
